Objective and use case
What you’ll build: A Raspberry Pi mailbox monitor that detects when the door opens with a magnetic reed switch, debounces the signal, logs the event with a timestamp, and sends a phone alert through ntfy.sh. It is a lightweight GPIO automation project with near-instant notification, typically under 1 second on a stable Wi‑Fi connection.
Why it matters / Use cases
- Get a real-time alert when mail is delivered instead of checking the mailbox manually.
- Reduce false triggers by debouncing switch input, useful for windy outdoor enclosures or vibrating metal doors.
- Create a low-power home automation sensor with minimal compute load, often under 2% CPU and negligible GPU use on a Raspberry Pi.
- Keep a local event history to verify delivery times, for example logging 10:14:32 mailbox-open events for packages or letters.
- Use the same pattern for gate open alerts, shed access notifications, or cabinet-door monitoring.
Expected outcome
- A working reed-switch circuit connected safely to Raspberry Pi GPIO with a pull-up or pull-down resistor.
- Reliable open-event detection with debounce timing that filters brief contact bounce in milliseconds.
- Push-style alerts delivered to your phone via ntfy.sh with typical end-to-end latency of about 0.5–2 seconds, depending on network quality.
- Automatic startup at boot using systemd so monitoring resumes after power loss or reboot.
- Local timestamped logs you can review for troubleshooting, delivery tracking, or missed-notification checks.
Audience: Raspberry Pi beginners, DIY home automation hobbyists, and students learning GPIO input handling; Level: Basic
Architecture/flow: Reed switch changes GPIO state when the mailbox door opens → Raspberry Pi script reads and debounces the input → event is logged locally → HTTP notification is sent to ntfy.sh → phone receives the alert.
Educational validation note
Before publication, this case passed the Prometeo automated validation gate with status PASS. The validator checked the code blocks, article structure, copy/paste-safe commands and consistency with the supported device catalog.
Published validation evidence
- Automatic result: PASS.
- Parsed structure: 3 sections, 3 tables and 14 code blocks detected before publication.
- Checked code: 1 Python/py_compile, 1 service/config blocks, 10 Bash/copy-paste checks.
- Supported catalog: the article text was checked against Prometeo’s validation-capable device profiles, and unsupported stacks block publication.
- Report findings: no blocking findings.
This validation confirms syntax and tool compatibility for the published material, but it does not replace physical testing on your exact hardware, wiring and runtime environment.
Educational safety note
This project is an educational prototype, not a certified product. Before powering the setup, verify the pinout of your exact ULX3S board revision, keep FPGA I/O signals at 3.3 V, never connect 5 V directly to I/O pins, disconnect power before changing wiring, and use suitable external supplies for loads, motors or servos while sharing ground only when the wiring requires it.
title: Smart Mailbox Open Alert with Raspberry Pi
level: Basic
slug: practical-case-raspberry-pi
Smart Mailbox Open Alert with Raspberry Pi
This practical Raspberry Pi project builds a smart mailbox open alert.
A magnetic reed switch detects when the mailbox door opens, and the Raspberry Pi sends an alert to your phone using ntfy.sh.
Conceptual block diagram
High-level view: what enters the system, what each block processes, and what comes out.
Functional architecture
Conceptual signal and responsibility flow between device blocks.
Validation path
Conceptual summary of the tools used to check the published material.
What this project does
- Detects mailbox door state with a reed switch
- Debounces the input to reduce false triggers
- Sends a push-style network alert when the mailbox is opened
- Logs each open event locally with a timestamp
- Runs automatically at boot with
systemd
Safety note
This project is for low-voltage GPIO only. Do not connect Raspberry Pi GPIO pins directly to mains voltage, powered doorbells, electric locks, or unknown wiring inside a metal mailbox. If the mailbox is outdoors, protect the Pi and wiring from moisture and use proper strain relief.
Parts
- Raspberry Pi with network access
- microSD card with Raspberry Pi OS
- 1 magnetic reed switch, normally open
- 1 x 10 kOhm resistor
- Jumper wires
- Breadboard or soldered prototype board
Wiring
The reed switch is used as a contact sensor. When the mailbox door opens, the switch changes state and the Raspberry Pi can trigger the smart mailbox open alert.
Pin table
| Function | Component pin | Raspberry Pi pin |
|---|---|---|
| 3.3 V pull-up source | 10 kOhm resistor end 1 | 3.3 V, physical pin 1 |
| Signal node | 10 kOhm resistor end 2 + reed switch end 1 | GPIO17, physical pin 11 |
| Ground path | Reed switch end 2 | GND, physical pin 6 |
Logic
| Mailbox state | Reed switch | GPIO17 state |
|---|---|---|
| Closed, magnet near switch | Closed contact | LOW |
| Open, magnet away from switch | Open contact | HIGH |
This wiring uses an external pull-up resistor to 3.3 V. The GPIO reads:
0when the mailbox is closed1when the mailbox is open
System setup
Update the system and install the required packages:
sudo apt update
sudo apt install -y python3 python3-gpiozero python3-requests
Create a project directory:
mkdir -p /home/pi/mailbox-alert
Python application
Save this file as /home/pi/mailbox-alert/mailbox_alert.py.
#!/usr/bin/env python3
from gpiozero import Button
from signal import pause
from datetime import datetime
import os
import socket
import requests
PIN = 17
LOG_FILE = "/home/pi/mailbox-alert/mailbox_events.log"
HOSTNAME = socket.gethostname()
TOPIC = f"{HOSTNAME}-smart-mailbox-open-alert"
NTFY_URL = f"https://ntfy.sh/{TOPIC}"
sensor = Button(PIN, pull_up=False, bounce_time=0.2)
def write_log(message: str) -> None:
timestamp = datetime.now().isoformat(timespec="seconds")
line = f"{timestamp} {message}\n"
with open(LOG_FILE, "a", encoding="utf-8") as log_file:
log_file.write(line)
def send_alert() -> None:
now = datetime.now().strftime("%Y-%m-%d %H:%M:%S")
title = "Mailbox opened"
body = f"Smart mailbox open alert from {HOSTNAME} at {now}"
headers = {
"Title": title,
"Priority": "default",
"Tags": "mailbox,postbox,package"
}
try:
response = requests.post(
NTFY_URL,
data=body.encode("utf-8"),
headers=headers,
timeout=10
)
response.raise_for_status()
write_log(f"ALERT_SENT topic={TOPIC} status={response.status_code}")
except requests.RequestException as exc:
write_log(f"ALERT_FAILED error={exc}")
def on_open() -> None:
write_log("MAILBOX_OPEN")
send_alert()
def main() -> None:
write_log(f"START topic={TOPIC} pin={PIN}")
sensor.when_pressed = on_open
pause()
if __name__ == "__main__":
os.makedirs("/home/pi/mailbox-alert", exist_ok=True)
main()
Make it executable:
chmod +x /home/pi/mailbox-alert/mailbox_alert.py
Test the smart mailbox open alert manually
Run the application in a terminal:
python3 /home/pi/mailbox-alert/mailbox_alert.py
Then open the mailbox door. You should see a new event in the log file:
tail -f /home/pi/mailbox-alert/mailbox_events.log
Subscribe on your phone or another device to:
https://ntfy.sh/<your-hostname>-smart-mailbox-open-alert
For example, if your Raspberry Pi hostname is raspberrypi, the topic is:
https://ntfy.sh/raspberrypi-smart-mailbox-open-alert
You can check your hostname with:
hostname
Run at boot with systemd
Create /etc/systemd/system/mailbox-alert.service:
[Unit]
Description=Smart Mailbox Open Alert
After=network-online.target
Wants=network-online.target
[Service]
Type=simple
User=pi
WorkingDirectory=/home/pi/mailbox-alert
ExecStart=/usr/bin/python3 /home/pi/mailbox-alert/mailbox_alert.py
Restart=on-failure
RestartSec=5
[Install]
WantedBy=multi-user.target
Enable and start the service:
sudo systemctl daemon-reload
sudo systemctl enable mailbox-alert.service
sudo systemctl start mailbox-alert.service
sudo systemctl status mailbox-alert.service --no-pager
Validation method
To validate that this smart mailbox open alert works correctly:
- Start the service.
- Close the mailbox so the magnet is near the reed switch.
- Open the mailbox once.
- Confirm:
- one
MAILBOX_OPENentry appears in the local log - one
ALERT_SENTentry appears in the local log - one notification arrives on the subscribed
ntfy.shtopic - Repeat 10 open/close cycles.
Expected evidence
| Check | Expected result |
|---|---|
| GPIO detection | One trigger when door opens |
| Local log | Timestamped MAILBOX_OPEN and ALERT_SENT lines |
| Network alert | One notification per open event |
| Repeatability | Consistent behavior across repeated open/close cycles |
Troubleshooting
No alert arrives
Check that the Pi has internet access:
ping -c 3 ntfy.sh
Check the service logs:
journalctl -u mailbox-alert.service --no-pager -n 50
False triggers
- Increase
bounce_timefrom0.2to0.5 - Mount the magnet and reed switch more securely
- Keep sensor wires short or twisted to reduce noise
Input never changes
Verify the GPIO state with:
python3 -c "from gpiozero import Button; from time import sleep; s=Button(17, pull_up=False); print(s.is_pressed); sleep(1)"
Result
You now have a smart mailbox open alert built on a Raspberry Pi.
When the mailbox door opens, the reed switch changes state, the Pi detects the event, and an alert is sent automatically.
